160A video inspection system has been designed as a user friendly and economical way of solving hidden problems and increasing productivity. (e.g. inspect HVAC system, mechanical equipments and engines).

The product has a high clarity 3.5″ diagonal color LCD. It uses interchangeable probes and can be connected to probes with different length and diameter (units comes with a standard 12mm probe, customized camera head and probe also available). The adjustable LED lights set around the camera head help the user to see inside dark gaps and holes. Several accessories can be equipped on the tip of the probe, making it more flexible and adaptive. The accessories of 12mm camera probe are magnetic tip, hook tip and mirror tip.

160A has a TV-out interface to transmit real time images to a TV screen. It is capable of image zooming and image rotation. This model has the advantages of portability, high clarity images, stable performance and easy operation. It is widely used in applications such as the industry, building, aviation, vehicles maintenance, mining and archaeology.

Technical Specifications

Function：
    ● 3.5″high resolution full color LCD display
    ● 300,000-pixel CMOS image sensor with an image resolution of 640 × 480 pixels
    ● Outer diameter of camera head optional :12mm、9mm and 5.5mm
    ● Flexible hose that can be memorized, lens hose waterproof rating IP67
    ● White LED lighting with large viewing angle
    ● LED brightness is adjustable
    ● Image 90 degree rotation function
    ● Image zooming 2 times
    ● With TV output interface function
    ● Equipped with a variety of pick-up accessories (magnets, hooks, mirrors, etc.)
    ● 4 AAA alkaline batteries
Application:
    Widely used in industrial, building, aviation, vehicle maintenance, mining, archaeology, etc., can provide you with flexible observation performance, allowing you to quickly diagnose equipment wear, solder joints, loose parts, etc.
