The 33622A waveform generator with exclusive Trueform signal generation technology offers more capability, fidelity and flexibility than the previous generation Direct Digital Synthesis (DDS) generators. Use them to accelerate your development process from start to finish. Keysight's Trueform technology offers a new alternative that blends the best of DDS and point-per-clock architectures, giving you the benefits of both without the limitations of either. Trueform technology uses an exclusive digital sampling technique that delivers unmatched performance at the same low price you are accustomed to with DDS.
- So you can perform deeper testing - see One Page Summary for further information
- Easily generate the full range of signals you need for the most demanding measurements
- Select just the capabilities you need now, then upgrade easily when your needs change
- 1 ps jitter, 1/100th the jitter of DDS generators
- 5x lower harmonic distortion than DDS
- Compatible with Keysight BenchVue software
- Provides standard PRBS patterns, PN3 through PN32 Select PN type, set bit rate, set edge times
- Easily set up & control your 33600A remotely over LAN using the built-in LXI Web browser
- Various upgrades available including bandwidth, GPIB and Memory
- 1 µHz to 120 MHz sine
- 2-Channels
- Sine, Square, Ramp, Pulse, Triangle, Gaussian Noise, PRBS (Pseudorandom Binary Sequence), DC
- AM, FM, PM, FSK, BPSK, PWM, Sum (carrier + modulation)
- Built-in ARB: Cardiac, Exponential Fall, Exponential Rise, Gaussian Pulse, Haversine, Lorentz, D-Lorentz, Negative Ramp, Sinc
- User Defined Arb: Up to 4 MSa (64 MSa with Option MEM) with multi segment sequencing
- Amplitude ranges: 1 mVpp up to 10 Vpp
- LAN (LXI-C), USB included
- Optional GPIB (3446GPBU)
Clean, Low-Distortion, Stable, and Reliable Signals
When testing a device, you need a source that produces a clean, low-distortion, stable and reliable signal. Keysight's exclusive Trueform technology gives you the confidence to produce the exact waveforms you need with best-in-class signal fidelity, surpassing the performance of direct digital synthesis (DDS) technology. With Trueform Series Waveform and Function Generators, you can define any waveform shape and any waveform length using point-by-point arbitrary waveform capability. Anti-aliasing technology ensures your waveforms are exceptionally accurate, and playable at any rate you select. Play signals as defined, at the exact sample rate, without missing short-duration anomalies critical for testing device reliability.
- Better signal integrity
Get the waveform you want, regardless of frequency or sample rate.
- Lower harmonic distortion
Measure your design characteristics, not those of your waveform generator.
- Reduced jitter
Less jitter gives you exceptionally low phase noise for the most accurate representation of signals. - Variable bandwidth noise
Adjust the bandwidth of the built-in noise generator to control the frequency content of your signal.
- Waveform summing and combining capability
You can create dual-tone multifrequency signals without a dual-channel generator. On a two-channel model, you can sum and combine up to four signals. - BenchVue enabled
Intuitively control your waveform generators, build automated tests, and design custom waveforms from your PC.
Exclusive Trueform technology
- Unmatched capabilities for generating a full range of signals for your most demanding measurements
- Sine waves with 5x lower harmonic distortion for more pure signals
- Pulses up to 100 MHz with
- Trueform arbitrary waveforms with sequencing for more accurate representation of user-defined signals
Instrument features
- 1 GSa/s sampling rate for higher time resolution arbitrary waveforms
- 14-bit resolution with 1 mVpp to 10 Vpp amplitude for greater amplitude accuracy
- 4 MSa/channel standard waveform memory, optional 64 MSa/channel for your longest waveforms
- USB, LAN (LXI-Core), GPIB optional for quick and easy connectivity to PC or network
- BenchVue Enabled. Control your waveform generator from your PC easily.
Waveform creation and editing
