CANlink is a evaluation and analysis tool of CAN communication.
CANlink is used in development phases of ECU and communication system
to analyze characteristics and simulate CAN communication for evaluation purpose.
1. Main features
Monitoring and Analyzing CAN data
■ Convenient Interface
■ Analyze data using CAN database
■ Filter for analyzing a specific message or channel
Save and transmit CAN data
■ Save data
■ Analyze saved data
■ Transmit time and/or event triggered CAN messages
1.1 Analysis Window
Analysis Window is used to analyze CAN data
Graph
| Display the calculated signal value, which transmitted and received data is interworking with Database, as a graph
|
|---|---|
Trace
| Display information of messages and signals with interworking transmitted and received data with Database
|
Generator
| Set and transmit a message and signal
|
Bus Statistics
| Display Bus load, Bus status and message counts etc. of channel
|
1.2 Docking Window
Frequently used functions and setup are available to implement docking windows
which are anchored anywhere within the CANlink frame
System Configuration
| Configure windows, blocks and filters. They can be added/deleted or Enable/Disable and open configuration window in the popup menu
|
|---|---|
Script Configuration
| Link the Script file(*.lua) which is implemented functions for individual applications
|
Database Viewer
| Display information of messages and signals in the linked CAN Database(*.dbc)
|
Output
| Display system information, such as operation status, information, warnings, errors and Script output
|
Panel Configuration
| Panel configuration is used to link Panel files, created by Panel Editor, to CANlink
|
1.3 Function Block
Function Block provides functions of save, replay and filter etc.
They can be added/deleted/configured on the System Configuration
Record
| Record block is for saving data occurred in network. Data is saved as ASCII file(*.asc)
|
|---|---|
Replay
| Replay block makes it possible to replay saved data, which have been recorded by Record block
|
Channel Filter
| Select the channel and Filter type; Pass, Stop
|
Message Filter
| Add ID area and select Filter type; Pass, Stop
|
1. System Requirements
■ Operating System : Microsoft Window operating systems
■ CPU : 2 GHz or more, and faster 32-bit (x86) or 64-bit (x64) processor
■ RAM : 2G or more
■ HDD : 1G hard disk space available
2. Supporting Hardware
■ CANlink Interface
