Power: 10KW
Current: 0~32A/0~320A
Voltage: 0~600V
Min.Operation Voltage: 10V@320A


Protections:
  Over Power Protection (OPP): 105%
  Over Current Protection (OCP): 105%
  Over Voltage Protection (OVP): 105%
  Over Temp Protection (OTP): Yes


CC mode:
  Range: 0~32A/0~320A
  Resolution: 0.534mA/5.34mA
  Accuracy:    ±0.1%


CR mode:
  Range: 1.875~12500Ω/0.0192~1.875Ω
  Resolution: 0.0088mS/0.032mΩ
  Accuracy:    ±0.2%


CV mode:
  Range: 600V
  Resolution: 10mV
  Accuracy:    ±0.05%


CP mode:
  Range: 1000W/10000W
  Resolution: 16.7mW/167mW
  Accuracy:    ±0.5%


Measurement mode (Load):
  Voltage: 0 ~ 60V/60~600V, ±0.025%
  Current : 0 ~ 32A/32~320A, ±0.1%
  Power : 1000W/10000W, ±0.125%
Short circuit current: 320A
Dimension (HxWxD): 573 x 647 x 766 mm
Weight: 130 kg
Input: 115/230Vac, 50/60Hz
Optional interface: GPIB, RS232, USB, LAN
