High-speed response SW(switching) operation is available in the CC or CR discharging mode. It features the maximum response of 10µs (in the CC discharging mode).
100 sequence memory Storing on panel in the memory facilitates easy sequence operation.
External control Every model allows analog control according to external voltage (0 to 10V) and external resistance (0 to 10kOhm).
GP-IB interface Every model has the general purpose interface bus GP-IB as the standard feature.
Master slave parallel operation A maximum of five units can be connected in the parallel master slave operation mode.
Various protective functions Three protective functions are available: UVP (Under Voltage Protection), OCP (Over Current Protection) and OPP (Over Power Protection). Six alarm functions are available: RCP (Reverse Connection Protection) alarm, OPP (Over Power Protection) alarm, OVP (Over Voltage Protection) alarm, OCP (Over Current Protection alarm, OHP (Over Heat Protection) alarm and UVP (Under Voltage Protection) alarm.
Software start function The current rise time of the load side can be adjusted according to the rise time of the output voltage, when test the rise time of switching power supply.
