| Max. Scale Value | 0.1/0.2/0.5/1 A |
|---|---|
| Approximate Internal Resistance and Consumed Power | 0.2/0.3/0.4/.5 VA |
| Operating Principle | Moving iron type |
| Class | JIS C 1102: 1997 Class 0.5 |
| Operating Position | Horizontal |
| Scale Length | Approximately 135 mm (Deflection Angle: 85°) |
| Operating Frequency Range | 45 ~ 65 Hz |
| Linemax | 250V |
| Scale Divisions | 100 divisions |
| Operating Temperature Range | 0 ~ 40 ºC |
| Operating Humidity Range | 30 ~ 75% RH |
| Storage Temperature Range | -10 ~ 50 ºC |
| Storage Humidity Range | 25 ~ 80% RH |
| Approx. External Dimension | 195 x 170 x 87 mm |
| Approx. External Weight | 1.7 kg |
| Optional Accessories | 2291 01 Carrying case for 2013 2292 01 Carrying case for 2014 |
