30 mΩ (35.000 mΩ display Max., 1 µΩ resolution) to 3 MΩ range (3.5000 MΩ display Max., 100 Ω resolution), 9 steps
Measurement accuracy: ±0.020 % rdg. ±0.007 % f.s.

[at 30 mΩ range] 300 mA DC to [at 3 MΩ range] 500 nA DC

5.5 V DC max.

-10.0 to 99.9°C, accuracy: ±0.50°C (Temperature Sensor Z2001 and RM3544/RM35440-01 combined accuracy)

FAST (50Hz: 21ms, 60Hz: 18ms) / MED (101ms) / SLOW (401ms)

N/A

Temperature correction, comparator (ABS/REF%), key-lock (OFF, menu lock, all lock), display digit count selection function (5 digits/ 4 digits), automatic power supply frequency settings (AUTO/50Hz/60Hz), scaling, judgment sound setting, auto hold, averaging, panel store/panel load

N/A

[Only RM3544-01] Select from RS-232C, Printer (RS-232C), or USB
Remote function, communications monitor function, data output function

100 to 240 V AC, 50/60 Hz, Rated power consumption: 15 VA

215 mm (8.46 in) W × 80 mm (3.15 in) H × 166 mm (6.54 in) D mm
[RM3544] 0.9 kg (31.7 oz), [RM3544-01] 1.0 kg (35.3 oz)

[RM3544] Power cord ×1, Clip type lead L2101 ×1, Instruction manual ×1, Spare fuse ×1
[RM3544-01] Power cord ×1, Clip type lead L2101 ×1, Male EXT. I/O connector ×1, Instruction manual ×1, Application disc ×1, USB cable (A-to-B type) ×1, Spare fuse ×1
